Demonstration maskin Självlastande fodervagn: Krone TX 560 D

Krone TX 560 D 110.075 €

Dealer number 300367196

Pris inkl. skatt 19 % 110.075 €

Pris exkl. skatt 92.500 €

Fabrikat Krone

Modell TX 560 D

Årsmodell 2024

Ytterligare information

Typ: Demonstration maskin

Fabrikat: Krone

Modell: TX 560 D

Årsmodell: 2024

Detaljer

TX 560 D
(0010) Krone forage transport wagon
(0020) 200560130 TX 560 D
(0030) TT_1710 Low drive with drawbar
(0040) TT_0297 Tires 800/45 R 26.5 TL 174 D 10-hole
(0050) TT_3300 Tridem axle, air brake system + ALB
(0060) TT_0660 Lower hitch K80 + forced steering K50
(0070) TT_0810 Drawbar suspension
(0080) TT_1402 Metering unit / 2 rollers
(0090) TT_1550 Hydraulic unloading aid
(0100) TT_1310 Load compartment cover
(0110) B_091 40 km/h version
(0120) .
(0130) Technical data
(0140) Forage transport wagon
(0150) Capacity according to DIN 11741: 56 cbm
(0160) Overall length: 11,884 mm
(0170) Total width: 2,980 mm
(0180) Overall height: 3,950 mm
(0190) Track width: 2,050 mm
(0200) PTO speed: 1,000 rpm
(0210) Power requirement from 110 kW (150 hp)
(0220) Required hydraulic connections:
(0230) 2 x single-acting and 1 x double-acting
(0240) .
(0250) Basic equipment:
(0260) Hitch.
(0270) Articulated drawbar
(0280) Hydraulic drawbar suspension
(0290) PTO shaft,
(0300) Wide-angle joint on one side,
(0310) 1 3/8", Z=6, overload clutch
(0320) Load compartment.
(0330) Lowered scraper floor for additional
(0340) 2 cbm more loading volume
(0350) Single-frame concept for low unladen weight
(0360) Unladen weight and high payload
(0370) Mechanical scraper floor drive
(0380) with 1 1/4" roller chain
(0390) (incl. 3-year warranty)
(0400) Double scraper floor with four
(0410) Round steel scraper floor chains 14 x 50 mm
(0420) All-steel superstructure,
(0430) Side walls conical to each other
(0440) arranged
(0450) Access hatch
(0460) Hydraulic tailgate
(0470) Dosing unit
(0480) Two dosing rollers
(0490) Direct metering roller drive
(0500) incl. freewheel, secured via
(0510) Main PTO shaft
(0520) Further equipment:
(0530) Towing eye at the rear of the vehicle
(0540) Two LED work lights incl.
(0550) Control box with integrated rear
(0560) Flap control
(0570) LED load compartment lighting
Automatic translation from German without guarantee.
